MCB Supplementary Protector 6 A

The 6 A MCB Supplementary Protector is a compact, current-limiting miniature circuit breaker designed to provide additional protection for control circuits and equipment. Certified under UL 1077 and IEC 60947-2 standards, this device offers reliable overcurrent and short-circuit protection. It is particularly suitable for applications requiring precise protection in environments with limited space.

Key Features

• Rated Current: 6 A, suitable for protecting control circuits and equipment.

• Voltage Rating: Up to 480 V AC and 96 V DC, ensuring compatibility with various systems.

• Interrupting Capacity: Ranges from 10 kA to 15 kA, depending on the specific model, providing robust protection against fault currents.

• Trip Characteristics: Available in B, C, and D curves to match the load's inrush and steady-state current characteristics.

• Mounting Type: DIN rail mountable, facilitating easy installation in control panels.

• Terminal Type: Screw terminals for secure and reliable connections.

• Operating Temperature Range: Typically from –25 °C to +55 °C, accommodating various environmental conditions.

• Standards Compliance: UL 1077, CSA C22.2 No. 5, IEC 60947-2, CE, and RoHS compliant, ensuring global acceptability and safety

Typical Applications

• Control Panels: Protecting control circuits in industrial and commercial control panels.

• OEM Equipment: Providing supplementary protection in original equipment manufacturer (OEM) machinery.

• Automation Systems: Safeguarding components in automated systems and PLCs.

• Motor Protection: Protecting motors and associated control circuits from overcurrent conditions.

Why Choose This 6 A MCB Supplementary Protector?

• Reliable Protection: Offers dependable overcurrent and short-circuit protection, enhancing system reliability.

• Compact Design: Its small footprint allows for installation in space-constrained environments.

• Versatility: With multiple trip characteristics and voltage ratings, it suits a wide range of applications.

• Global Compliance: Meets international standards, making it suitable for global applications.

• Easy Installation: DIN rail mounting simplifies integration into existing systems.
